| 機組型號 |
輸出功率 KW KVA |
電流 A |
柴油機型號 | 缸數 |
缸徑*行程 mm |
潤滑油容量 L |
油耗 g/kw.g |
機組外形尺寸 L×W×H |
機組重量 kg |
|
| FM30GF | 30 | 37.5 | 54 | YC4FA40Z-D20 | 4 | 96*103 | 8 | 215 | 1500*700*1100 | 500 |
| FM40GF | 40 | 50 | 72 | YC4FA55Z-D20 | 4 | 96*103 | 8 | 215 | 1500*700*1100 | 550 |
| FM50GF | 50 | 62.5 | 90 | YC4FA75L-D20 | 4 | 96*103 | 12 | 215 | 1800*800*1300 | 750 |
| FM40GF | 40 | 50 | 72 | YC4D60-D21 | 4 | 108*115 | 12 | 215 | 1700*800*1300 | 600 |
| FM50GF | 50 | 62.5 | 90 | YC4D85Z-D20 | 4 | 108*115 | 12 | 215 | 1800*800*1300 | 800 |
| FM60GF | 60 | 75 | 108 | YC4D90Z-D21 | 4 | 108*115 | 15 | 215 | 1800*800*1300 | 850 |
| FM70GF | 70 | 87.5 | 126 | YC4A100Z-D20 | 4 | 108*125 | 16 | 215 | 1800*800*1300 | 900 |
| FM100GF | 100 | 125 | 180 | YC4A140L-D20 | 4 | 108*125 | 16 | 215 | 2100*900*1500 | 800 |
| FM90GF | 90 | 113 | 162 | YC6B135Z-D20 | 6 | 108*125 | 16 | 215 | 2100*900*1500 | 850 |
| FM100GF | 100 | 125 | 180 | YC6B155L-D21 | 6 | 108*125 | 16 | 215 | 2200*900*1500 | 950 |
| FM120GF | 120 | 150 | 216 | YC6B180L-D20 | 6 | 108*132 | 18 | 215 | 2200*900*1500 | 1000 |
| FM140GF | 140 | 175 | 252 | YC6B205L-D20 | 6 | 108*125 | 18 | 215 | 2200*900*1550 | 1200 |
| FM150GF | 150 | 188 | 270 | YC6A230L-D20 | 6 | 108*132 | 16 | 195 | 2500*1000*1600 | 1400 |
| FM160GF | 160 | 200 | 288 | YC6A245L-D21 | 6 | 108*132 | 16 | 195 | 2500*1000*1600 | 1500 |
| FM220GF | 220 | 275 | 396 | YC6MK350L-D20 | 6 | 120*145 | 25 | 195 | 2800*1100*1650 | 2000 |
| FM250GF | 250 | 313 | 450 | YC6MK420L-D20 | 6 | 123*145 | 25 | 195 | 3000*1100*1700 | 2200 |
| FM300GF | 300 | 375 | 540 | YC6MJ480L-D20 | 6 | 131*145 | 25 | 195 | 3200*1200*1700 | 2600 |
| FM350GF | 350 | 438 | 630 | YC6T550L-D21 | 6 | 145*165 | 50 | 195 | 3300*1200*1700 | 3000 |
| FM400GF | 400 | 500 | 720 | YC6T600L-D22 | 6 | 145*165 | 50 | 195 | 3500*1500*1800 | 3500 |
| FM450GF | 450 | 563 | 810 | YC6T660L-D20 | 6 | 145*165 | 50 | 195 | 3500*1500*1800 | 3600 |
| FM500GF | 500 | 625 | 900 | YC6TD780L-D20 | 6 | 145*165 | 50 | 195 | 3600*1600*2100 | 4200 |
| FM600GF | 600 | 750 | 1080 | YC6TD840L-D20 | 6 | 200*210 | 50 | 195 | 3600*1600*2100 | 4500 |
| FM650GF | 650 | 813 | 1170 | YC6C1020L-D20 | 6 | 200*210 | 180 | 195 | 4000*1500*2100 | 5200 |
| FM700GF | 700 | 875 | 1260 | YC6C1070L-D20 | 6 | 200*210 | 180 | 195 | 4200*1600*2100 | 5600 |
| FM800GF | 800 | 1000 | 1440 | YC6C1220L-D20 | 6 | 200*210 | 180 | 195 | 4600*1800*2500 | 7600 |
| FM880GF | 880 | 1100 | 1584 | YC6C1320L-D20 | 6 | 200*210 | 180 | 195 | 5200*2150*2600 | 8000 |
| FM1000GF | 1000 | 1250 | 1800 | YC12VC1680L-D20 | 12 | 200*210 | 180 | 195 | 5400*2150*2600 | 8500 |
| FM1100GF | 1100 | 1375 | 1980 | YC12VC1680L-D20 | 12 | 200*210 | 180 | 195 | 5400*2150*2600 | 8800 |
| FM1200GF | 1200 | 1500 | 2160 | YC12VC2070L-D20 | 12 | 200*210 | 180 | 195 | 5400*2150*2600 | 9000 |
| FM1320GF | 1320 | 1650 | 2376 | YC12VC2070L-D20 | 12 | 200*210 | 180 | 195 | 5400*2150*2600 | 10000 |
| FM1500GF | 1500 | 1875 | 2700 | YC12VC2070L-D20 | 12 | 200*210 | 180 | 195 | 5600*2300*2600 | 12000 |
| FM1600GF | 1600 | 2000 | 2880 | YC12VC2510L-D20 | 12 | 200*210 | 180 | 195 | 5600*2300*2600 | 12500 |
